5.2.4 Bottom
Blowdown
Timer Configurat
ion
Figure 5.2.4.i Configure Screen – Run Mode
In the Configure screen of Run mode, a
button
will appear, see Figure 5.2.4.i. Pressing this
button will take you to the timings and intervals adjust
ment screen.
5 Bottom Blowdown
Page 80
Mk7 Manual: Expansion Board Set-Up Guide
October 2014
89
91
