Commissioning Standalone Bottom Blowdown Module
To commission the bottom blowdown module for st
andalone operation, connect the bottom blowdown
module to the PC via the USB lead provided. Do
wnload the Bottom Blowdown Board Configurator
from the USB stick provided, and open the program.
Figure 5.3.i Disconnected
To begin the configuration press
bu
tton as displayed in Figure 5.3.i.
5 Bottom Blowdown
October 2014
Mk7 Manual: Expansion Board Set-Up Guide
