Menu Access
Choice of the display mode for the menus.
Simplified (default)
Access to the menus included in the Simplified mode.
Warning
: pressing the OK key to validate the passage
from the Extended to the Simplified mode causes a
movement of the arm (opening or closing), even if a
presence is detected by the Presence sensors.
Extended
Access to supplementary parameters.
Incompatibility table
of presence sensor (PS) use and operating modes:
compatible incompatible
Use mode
2 Contacts 1 Contact
Step by
Step
Dead Man 2 Contacts CFE
Sensor function
Desactivated
Opening
CL_Stop+CL
CL_OP+CL
Nothing_Stop+
CL
Nothing_OP+C
L
Nothing_Stop
Nothing_OP
