AutomationDirect DL105 - Data Label (DLBL); ASCII Constant (ACON)

Standard
RLL Instructions
5--84
Standard RLL Instructions
Message Instructions
DL105 PLC User Manual, 3rd Edition
K aaa
DLBL
The Data Label instruction marks the
beginning of an ASCII / numeric data area.
DLBLs are programmed after the End
statement. A maximum of 32 DLBL
instructions can be used in a program.
Multiple NCONs and ACONs can be used
inaDLBLarea.
Operand Data Type DL130 Range
aaa
Constant K 1--FFFF
A aaa
ACON
The ASCII Constant instruction is used
with the DLBL instruction to store ASCII
text for use with other instructions. Two
ASCII characters can be stored in an
ACON instruction. If only one character is
stored in a ACON a leading space will be
inserted.
Operand Data Type DL130 Range
aaa
ASCII A 0--9 A--Z
K aaa
NCON
The Numerical Constant instruction is
used with the DLBL instruction to store the
HEX ASCII equivalent of numerical data
for use with other instructions. Two digits
canbestoredinanNCONinstruction.
Operand Data Type DL130 Range
aaa
Constant K 0--FFFF
Data Label
(DLBL)
ASCII Constant
(ACON)
Numerical
Constant
(NCON)
