AutomationDirect DL105 - Chapter 3: High-Speed Input and Pulse Output Features; Introduction

1
3
High-Speed Input and
Pulse Output Features
InThisChapter....
— Intro duction
— Choosing the HSIO Operating Mode
— Mode 10: High-Speed Counter
— Mode 20: Quadrature Counter
— Mode 30: Pulse Output
— Mode 40: High-Speed Interrupt
— Mode 50: Pulse Catch Input
— Mode 60: Filtered Inputs
