Installation, Wiring,
and Specifications
2--40
Installation, Wiring, and Specifications
DL105 PLC User Manual, 3rd Edition
sensors in the input circuit. Note that on the F1--130DA, the +24V output cannot
power its output circuits, because they require AC voltages.
External Power Requirements 100 -- 240 +10% --15%
Communication Port K--Sequence, 9600 baud, 8 data bits, odd parity
Programming cable type D2--DSCBL
Internal Field Supply Ratings +24VDC , 0.5A maximum, isolated
Operating Temperature
32 to 140 F(0to60_ C)
Storage Temperature
--4to158 F (-- 20 to 70_ C)
Relative Humidity 5 to 95% (non-condensing)
Environmental air No corrosive gases permitted
Vibration MIL STD 810C 514.2
Shock MIL STD 810C 516.2
Noise Immunity NEMA ICS3--304
Terminal Ty pe Removable
Wire Gauge One AWG14 or two AWG16, AWG24 minimum
Parameter High--Speed Inputs, X0 -- X3 Standard DC Inputs X4 -- X11
Input Voltage Range 10 -- 26.4 VDC 10 -- 26.4 VDC or 21.6 -- 26.4 VAC
Maximum Voltage 30 VDC (5 kHz maximum frequency) 30 VDC
Minimum Pulse Width
100 μS
N/A
ON Voltage Level >9.0VDC >9.0VDC
OFF Voltage Level <2.0VDC <2.0VDC
Input Impedance
2.8 kΩ @12--24VDC 2.8 kΩ @12--24VDC
Minimum ON Current >3 mA >3 mA
Maximum OFF Current <0.5mA <0.5 mA
OFF to ON Response
<50 μS
2 -- 8 mS, 4 mS typical
ON to OFF Response
<50μS
2 -- 8 mS, 4 mS typical
Status Indicators Logic side Logic side
Commons 4 channels / common x 1 bank 4 channels / common x 1 bank,
2 channels / common x 1 bank
Operating Voltage 20 -- 140 VAC, 47 -- 63 Hz
Peak Voltage 400 VAC
On Voltage Drop 1.3 VAC @ 2 A
Max Current 1.7 A / point, subject to derating
Max leakage current 1 mA @ 400 VAC
Max inrush current 30 A for 10 mS, 15 A for 100 mS
Minimum Load 10 mA
OFF to ON Response 8.33 mS @ 60 Hz, zero-crossing,
10 mS @ 50 Hz, zero-crossing
ON to OFF Response 8.33 mS @ 60 Hz, zero -crossing,
10 mS @ 50 Hz, zero-crossing
Status Indicators Logic Side
Commons 2 channels / common x 4 banks
Fuses None (external recommended)
F1--130DA
General
Specifications
DC Input
Specifications
AC Output
Specifications
