1 Overview
16 © Copyright Reserved Autonics Co., Ltd.
1.4 Specification
1.4.1 General specification
Model LP-S044-S1D0-C5T(R) LP-S044-S1D1-C5T(R)
Power supply 24VDC
Allowable voltage range 90 to 110% of power supply
Power consumption Max. 3.6W
Serial interface
Each of RS232C, RS422
(Asynchronous method)
Two of RS232C
(Asynchronous method)
Real-time controller RTC embedded
Battery life time
3 years at 25℃
Insulated resistance
Min. 100MΩ (at 500VDC megger)
Ground
3rd grounding(Max. 100Ω)
Noise immunity
The square wave noise (Pulse width 1 ㎲) by the noise simulator
with ±0.5kV
Withstanding voltage 500VAC (50/60Hz) for a minute
Vibration
Mechanical
0.75mm amplitude at frequency of 10 to 55Hz (for a minute) in each
of X, Y, Z directions for an hour
Malfunction
0.5mm amplitude at frequency of 10 to 55Hz (for a minute) in each
of X, Y, Z directions for 10 minutes
Shock
Mechanical 300m/s
2
(30G) X, Y, Z directions for 3 times
Malfunction 100m/s
2
(10G) X, Y, Z directions for 3 times
Environ
ment
Temperature
0 to 50℃, Storage: -20 to 60℃
Humidity 35 to 85% RH, Storage: 35 to 85% RH
Protection IP65F(for front panel)
Accessory Fixing bracket: 4 pcs, waterproof rubber ring, battery (included)
Approval
Unit weight
※
1
Approx. 454g (Approx. 312g)
※1: The weight in parentheses is only unit weight.
※Environment resistance is rated at no freezing or condensation.
