Autonics LP-S044 User Manual

12 Appendix
© Copyright Reserved Autonics Co., Ltd. 91
12.3 UW correspondence table
Description Bit range
Word
range
GP device(UB) GP device (UW)
X
Input device
X0 to X255F X0 to X255 UB70000 to UB7255F UW7000 to UW7255
Y
Output device
Y0 to Y255F Y0 to Y255 UB80000 to UB8255F UW8000 to UW8255
M
Auxiliary device
M0 to M9999F
M0 to
M9999
UB200000 to UB29999F UW20000 to UW29999
S
Step device
S0.0 to
S255.99
D
Data device
D0 to D9999F D0 to D9999 UW40000 to UW49999
T
Timer contact
T0 to T255 UB100000 to UB10015F
T
Timer present
value
T0 to T255 UW11000 to UW11255
T
Timer set value
T0 to T255 UW13000 to UW13255
C
Counter contact
C0 to C255 UB150000 to UB15015F
C
Counter present
value
C0 to C255 UW16000 to UW16255
C
Counter set
value
C0 to C255 UW18000 to UW18255
Z
Index device
Z0 to Z255F Z0 to Z255 UB067000 to UB06955F UW6700 to UW6955
F
Special device
F0 to F255F F0 to F255 UB64000 to UB6655F UW6400 to UW6655
V
Virtual device
V0 to V255F V0 to V255 UB061000 to UB06355F UW06100 to UW06355
L
Link device
L0 to L999F L0 to L999 UW38000 to UW38999
R
File device
R0 to R3999F R0 to R3999 UB020000 to UB05999F UW02000 to UW05999
