Q-12
MD5 Series
Dimensions
Connections
(unit: mm)
CW+
CW-
CCW+
CCW-
HOLD OFF+
HOLD OFF-
User
Controller
Alarm
output
+
-
Black
Green
Orange
Red
Blue
Motor
F.G.
100-220VAC 50/60Hz
3-5VDC
※
Please refer to Q-40 for
standard wiring.
20
42
5
40
156
108
122
133.5
5.4
4-M4 Tap Depth: 8
7
120
170
5-Phase Stepper Motor Driver (2.8A/Phase, AC Power)
