Autonics MD5 Series User Manual

Q-22
MD5 Series
Dimensions
MD5-HD14-2X
MD5-HD14-3X
(unit: mm)
5
20
180
40
80
40
80
5
245
Accessory
Connector Qty.
Manufacturer Model No. MD5-HD14-2X MD5-HD14-3X
A Power 2-wire housing Yeonho electronics YH396-02V 1 1
B Motor 5-wire housing Yeonho electronics YH396-05V 2 3
C Signal 6-wire housing JST XAP-06V-1 2 3
- Power/Motor terminal pin Yeonho electronics YT396 12 17
- Signal terminal pin JST SXA-001T-P0.6 12 18
※
Accessory connector specication
Time Chart
1-pulse input method
2-pulse input method
CW
[H]
[L]
CCW
[H]
[L]
Rotation
position
CW CCW
CW CCW
[H]
[L]
[L]
[H]
CW
CCW
Rotation
position
※
Do not input CW, CCW signals at the same time in 2-pulse input method.
It may not operate properly if another direction signal is inputted when one of CW or CCW is [H].
CW
190
4-M3 Tap
5
66
80
180
2-axis
1-axis
A
BC
260
5
66
249
4-M3 Tap
3-axis
2-axis 1-axis
A
BC
