Q-6
MD5 Series
Connections
Dimensions
(unit: mm)
※
Please refer to Q-40 for
standard wiring.
Division selection
signal
Zero point
excitation
output signal
CW+
CW-
CCW+
CCW-
HOLD OFF+
HOLD OFF-
User
Controller
+
+
+
-
-
-
Black
Green
Orange
Red
Blue
POWER
20-35VDC
Motor
4.5
20
39.5
100
86
76.5
74
38
4.5
94
100
105
