Autotrol Logix 764 User Manual

5
Figure 2 764 Controller Identification
Figure 3 Remote Start/Multi-Tank Lockout Cable
Figure 4 Twin Sensor Cable
Figure 5 Twin Cable Extension
Time/Day
Regeneration Time
Salt Amount
SU MO TU WE TH FR SA
g/L
PM
MIN
KG
x100
x2
P
HC
Capacity
Hardness
Lbs/ft³
LCD Display
Manual Regen Button
Down Button
Set Button
Up Button
Main Motor &
Optical Sensor
Connection
AC Adapter
(low voltage)
Input
Front
Back
Extension Cable
Connection
No-Salt Detector
(Chlorine Generator)
Connection
Lockout & Remote
Connection
Regen/Start
Multi Single Tank
Dry Contact Signal Input
Turbine Input
