Avaya E129 - SAFETY COMPLIANCES; WARRANTY

FIRMWARE VERSION 1.0.5.2 E129 SIP DESKPHONE USER MANUAL Page 11 of
60
Table 3: E129 SIP DESKPHONE CONNECTORS
Handset Port
RJ9 handset connector port
Headset Port
RJ9 headset connector port, supporting EHS (Electronic Hook-Switch) with
Plantronics headsets
LAN Port
10/100Mbps RJ-45 port connecting to Ethernet, integrated PoE (GXP1165 only)
PC Port
10/100Mbps RJ-45 port for PC connection
Power Jack
5V DC Power connector port
To set up the E129 SIP DESKPHONE, follow the steps below:
1. Attach the phone stand to the back of the phone where there are slots;
2. Connect the handset and main phone case with the phone cord;
3. Connect the LAN port of the phone to the RJ-45 socket of a hub/switch or a router (LAN side of the
router) using the Ethernet cable;
4. Connect the 5V DC output plug to the power jack on the phone; plug the power adapter into an
electrical outlet. If PoE switch is used on GXP1165 in step 3, this step could be skipped;
5. The LCD will display provisioning or firmware upgrade information. Before continuing, please wait for
the date/time display to show up;
6. Using the keypad configuration menu or phone's embedded web server (Web GUI) by entering the IP
address in web browser, you can further configure the phone.
SAFETY COMPLIANCES
The E129 SIP DESKPHONE phone complies with FCC/CE and various safety standards. The E129 SIP
DESKPHONE power adapter is compliant with the UL standard. Use the universal power adapter provided
with the E129 SIP DESKPHONE package only. The manufacturer’s warranty does not cover damages to
the phone caused by unsupported power adapters.
WARRANTY
If the E129 SIP DESKPHONE phone was purchased from a reseller, please contact the company where
the phone was purchased for replacement, repair or refund. If the phone was purchased directly from
Grandstream, contact the AVAYA Sales and Service Representative for a RMA (Return Materials
