USING THE E129 SIP DESKPHONE
GETTING FAMILAR WITH THE LCD
E129 SIP DESKPHONE has a dynamic and customizable screen. The screen displays differently
depending on whether the phone is idle or in use (active). The following table describes the items
displayed on the E129 SIP DESKPHONE idle screen.
Table 4: E129 SIP DESKPHONE DISPLAY DEFINITIONS
DATE AND TIME
Displays the current date and time. It can be synchronized with Internet time
servers.
LOGO NAME
Displays company logo name. This logo name can be customized via xml screen
customization. The maximum size for logo name is 26 characters in English
(approximately).
NETWORK STATUS
Shows the status of network in the middle of the screen. It will indicate whether
the network is down or starting.
STATUS BAR
Shows the status of the phone for registration status, call features and etc, using
icons as shown in the next table.
SOFTKEYS
The softkeys are context sensitive and will change depending on the status of
the phone. Typical functions assigned to softkeys are:
 NextScr: Toggles among idle screen, weather information, IP Address
and extension number;
 Headset: Onhook/offhook using headset; or toggle to headset mode;
 FwdAll: Unconditionally forwards the calls to another number;
 Missed: Shows unanswered calls to this phone;
 Redial: Redials the last dialed out number.
Table 5: E129 SIP DESKPHONE LCD ICONS
Registration Status: Registered.
Registration Status: Not Registered.
Handset Status.
