FIRMWARE VERSION 1.0.5.2 E129 SIP DESKPHONE USER MANUAL Page 32 of
60
as an administrator or an end user.
 Status: Displays the Account status, Network status, and System Info of the phone;
 Account: To configure the SIP account;
 Basic Settings: To configure basic network settings, time settings, Line keys, and etc;
 Advanced Settings: To configure advanced network settings, upgrading and provisioning, language
settings, call features, and etc.
STATUS PAGE DEFINITIONS
MAC Address
Global unique ID of device, in HEX format. The MAC address will be
used for provisioning and can be found on the label coming with original
box and on the label located on the back of the device.
IPv4 Address
The IPv4 address obtained on the phone.
IPv6 Address
The IPv6 address obtained on the phone.
Product Model
Product model of the phone.
Part Number
Product part number.
Software Version
 boot: boot version number;
 core: core version number;
 base: base version number;
 prog: program version number. This is the main firmware release
number, which is always used for identifying the software system of
the phone;
 dsp: DSP version number.
System Up Time
System up time since the last reboot.
System Time
Current system time on the phone system.
Registered
SIP account registration status.
PPPoE Link Up
PPPoE connection status.
Service Status
GUI and Phone service status: running or stopped.
Core Dump
Core dump file that could be downloaded for troubleshooting purpose.
ACCOUNT PAGE DEFINITIONS
Account Name
The name associated with the SIP account.
SIP Server
The URL or IP address, and port of the SIP server. This is provided by
your VoIP service provider (ITSP).
