Migration tasks
Issue 2.1 June 2006 455
Migration tasks
The information in this section is based on the assumption that the media server complex is
installed, configured, and operational.
!
CAUTION:
CAUTION: This migration affects service. When the PPN is turned off, the system drops all
calls. Service returns when the media server takes control of the IPSIs.
The following list describes the general migration procedures:
● Turn off the processor gracefully - pre-conversion administration
● Replace the processor circuit pack or tone clock circuit pack with an IP Server Interface
(IPSI) circuit pack
● Connect the IPSI circuit pack to the Ethernet switch on the customer network
● Assign an IP address to the IPSI circuit pack
You can reuse the translations from the existing system when you migrate to an S8500 Media
Server.
Note:
Note: You must install the new Communication Manager license file on the media
server before you make the change or the system will not run.
Perform the following tasks to convert a processor port network to a port network (CMC).
Premigration administration:
● Connecting to the processor on page 457
● Verifying system status on page 457
● Recording all busyouts on page 458
● Recording node names and IP addresses on page 458
● Saving translations on page 458
Migration tasks:
● Accessing the media server maintenance web interface on page 459
● Copying translation files to media server on page 459
● Restoring translation files on page 459
● Administering the IPSIs on page 460
● Adding IPSI translations to Communication Manager on page 461
● Setting the alarm activation level on page 461
● Backing up translations on page 461
