17
2PRODUCT DESCRIPTION
2.1 OVERVIEW
ALS
104
GB
2.1.5 Technical specifications
Characteristics
1) At a speed range of 5 to 30m/min
Labels
2) Depending on the dispensing edge width.
Label sensor
Power supply
Electronics
Dispensing speed: up to 30m/min
Labelling halt precision
1)
at the peeling edge:
± 0.5 mm
Speed control: constant speed or auto-
matic speed adaption
using speed sensors
Label material: Converted self-adhesive
label material with liner
Internal rewinding yes
Material width
(including backing pa-
per):
10 to 110mm
2)
Label width: bis 110 mm
2)
Label length: 5 to 600 mm
Label roll
Winding direction:
Unwinder (outer) Ø:
Rewinder (outer) Ø:
Core (inner) Ø:
face in or face out
up to 300mm
up to 200mm
38.1/ 76.2/101.6mm
(1.5 /3 /4”)
Distance to peel edge
L-shape dispensing
edge:
V-shape dispensing
edge (fix):
V-shape dispensing
edge (variable):
19mm
77mm
79-207 mm
Transmission sensor: Wenglor OPT242-P800
optical, NPN
System voltage: 115V (AC) at 60Hz po-
wer frequency
230V (AC) at 50 Hz po-
wer frequency
Power consumption: 300VA
Current consumption: 2A at 115 V system
voltage
1A at 230V system
voltage
Processor: 16Bit DSP
RAM: 4kB
ROM: 64kB
Slot for plug-in-cards: none
Realtime-clock: none
Control panel: graphical display with
128x 32pixels, 2 lines,
5 buttons
Control panel interface: RS422 (Mini DIN 6 con-
nection) for remote cont-
rol
maximum cable length:
10m
Service interface: RS232C, D-Sub 9
Sensor interfaces for
external sensors
Label sensor:
Product sensor:
APSF-Sensor (Rotary
encoder):
Outer diameter
checking sensor:
(opto-isolated; D-Sub 9
connector, each on a se-
parate 4-pin M12 connec-
tor)
Wenglor OPT242-P800
(adjustable by potentio-
meter) or alternate sen-
sors or signals,
PNP/NPN
3)
, 24V
PNP/NPN
3)
, 24V
single-phase, PNP/
NPN
3)
/ P-P, 24V,
max. 20kHz
PNP/NPN, 24V
