22
2PRODUCT DESCRIPTION
2.2 OPTIONS
ALS
104
GB
Outer Diameter control sensor
The outer diameter control sensor (OD sensor) triggers
a warning, if the label roll outer diameter falls below a
certain, adjustable value.
Dust/Splash guard
Available only for ALS20X.
Additional sealing of the electrical connections and of
the housing fulfils the requirements of the IP65 protec-
tion class [19].
Additional material guide disk
The additional material guide disk [21A] improves the
lateral guiding of the material roll. This option is espe-
cially recommended, if very narrow material (< 30 mm
width) is processed.
[19] OD sensor (pictured red resp. dark gray)
[20] Dust/splash guard of the electrical connections (pictured red
resp. dark gray)
[21] Additional material guide disk (A)
A
