40
4OPERATION
4.2 CONFIGURATION AND MONITORING
ALS
104
GB
Label position on the product
Prerequisites:
– The label length must be specified.
– The label stop position must be set.
The Start Offset is set in dispensing mode with the right
two keys (see “Dispensing mode” on page 24).
– The label should be flush with the front edge of the
product:
£ Enter the distance between the product sensor and
the label sensor [49A].
– The label should stop at a distance from the front
edge of the product:
£ Increase the start offset [50A] to increase the
distance to the product’s front edge.
[49] Distance between the product sensor (left) and the label
sensor (right).
A
[50] Distance (A) between the label and the product’s front
A
