MBOX Control Software Overview
24
Group All Monitor Mixes
When enabled, Alt, Headphone 1, Headphone 2, and Bluetooth outputs mirror Main. Group All Monitor Mixes can be enabled in either
Standard or Advanced Mix Mode.
• All Monitor outputs share the same Input to Output Mix. Individual mix layer controls are linked together so that, for example,
when you move the
Internal 1/2 fader in the single mix monitor group, that fader moves for all of those grouped/linked output mix-
ers).
• Main Mix Layer (which is only accessible in Advanced Mix Mode) is locked out for the user and input faders are set at unity and
pans centered.
• S/PDIF is included in the Monitor output single mix group if the
Mirror Main to S/PDIF preference is enabled.
• FX 1, FX 2/Hi-Z Output and ADAT 1–8 are not part of the single Mix monitor group and are mixed the same way as in Standard
Mix Mode.
Mirror Main to S/PDIF
When Mirror Main to S/PDIF is enabled, the mix routed to the MAIN output is also sent (mirrored) to the S/PDIF output. This provides
a convenient way to use the S/PDIF output as another monitor output option. Cycling through monitor outputs will cycle from
Main, to
Alt to Dig (S/PDIF). When S/PDIF is selected, MUTE, DIM, and other monitor controls apply to the Dig (S/PDIF) output the same as
they do for MAIN and ALT.
User Action Buttons 1–4 Assignment
Each of the four User Action buttons can be assigned to perform two separate functions, one for when the corresponding User Action
button is pressed and a second function for when that button is pressed and held. The current User assignments are shown in the Toolbar.
Actions
The following tables list the available Internal Actions.
Internal Actions
For more information, see Customizing the User Action Buttons 1–4.
Available Internal Actions
Internal Actions Notes
MAIN Monitor Mute Toggle between Muted and Unmuted states
ALT Monitor Mute Toggle between Muted and Unmuted states
Bluetooth Monitor Mute Toggle between Muted and Unmuted states
Standard/Advanced Mix Mode Toggle On/Off
Group Monitor Outputs Toggle “Group All Monitor Mixes” option on/off
Phase (of selected channel)
High Pass Filter (of selected channel)
Soft Limit (of selected channel)
EQ Bypass (of selected channel)
EQ to DAW (of selected channel)
Solo (of selected channel)
Mute (of selected channel)
User Presets Opens the User Presets dialog
Preferences
HI-Z OUT TO AMP Ground Lift Toggle ground lift on HI-Z OUT TO AMP
