Avid NEXIS | PRO Controller in Slot 1 (for 4TB SATA Drives)
Rear View Features of Avid NEXIS | PRO
Avid NEXIS | E2, Avid NEXIS | E2 SSD, and Avid NEXIS | SDA Rear View
The rear of the chassis provides access to the Controllers and the PCMs.
In Avid NEXIS | E2 and Avid NEXIS | SDA the controller is in slot 0 (top).
Avid NEXIS | E2 and Avid NEXIS | SDA Rear View
In Avid NEXIS | E2 SSD the controller is in slot 1 (bottom), upside down.
Avid NEXIS | E2 SSD Rear View
Component Notes
Power Supply/Cooling
Modules (PCM)
764W power supply and cooling fan modules.
The left power supply is numbered 0, the right is numbered 1, in event and error messages.
Controller Avid NEXIS | PRO (2TB drives)—Uses one Controller in slot 0
Avid NEXIS | PRO (4TB drives)—Uses one Controller in slot 1, upside down (can be one of two
types of Controllers)
Redundant controllers not supported
