Grounding and Shielding
18
The following materials are recommended for grounding:
Fig. 7 Mounting of ground braid at insert nut
Insert nut d9
Contact disk 6.1
Cu-band 11 x 2
Disk 6.4
DIN rail 35 x 7.5
7.5
11
3
5
2
Screw M6 x 25
Mounting panels
Fig. 8 Alternative mounting of ground braid at ground terminal
=EX0441= Ground braid: tin-plated Cu 10 mm
2
(rolled)
=EU1675= Ground terminal 10 mm
2
=EU2168= Pin-type cable socket 10 mm
2
11
3
5
