Operating Manual
45
6Technical Data
6.1 Data
6.2 CE Compliance
89/336/EEC Directive on Electromagnetic Compatibility met by
complying with the following standards:
EN 61326:97/A1:98/A2:01 Electrical Equipment for Measurement,
Control and Laboratory Use
EMC (Electromagnetic Compatibility) Requirements
Area of application:
Class A equipment:
Equipment suitable for use in facilites other than domestic facilites and
those directly connected to a low voltage power supply network which
supplies buildings used for domestic purposes.
73/23/EEC Low Voltage Directive met by complying with the following
standard:
EN 61010-1:2001 Safety Requirements for Electrical Equipment for
Measurement, Control and Laboratory Use
Case:
55 mm x 264 mm (6 HU) x 180 mm (width x height x depth)
Supply voltage: 24 V DC +
20 %
Reverse battery protection provided
Power consumption: 12.5 watt (typical) without external load
Ambient temperature: 0 to 60 °C
Storing temperature: -20 to 85°C
Relative humidity for storage: 0 to 90 %
Relative humidity for operation: 20 to 80%, no condensation
Operating altitude: 3000 m max. above sea level
Number of channels: 4 analog channels with +
11 V or + 22 mA
2 frequency outputs with RS422 and
single signal 5 - 15 V
Interfaces: 3 IEEE1394 bus interfaces
2 Add-on interfaces to F-FEM-DIO
Cable lengths: IIEEE1394 max. 10 m, for longer cables: repeater
Add-on max. 15 m
Weight: 1.12 kg
Table 16

AVL F-FEM-DAC Specifications
