Pin assignment
38
4.5.4 Power Supply Connection: X11
Fig. 26 Power supply connection: X11
Pin Signal Description
1 GND 24 Ground
2 PE Protective ground
3 24 V + power supply
Case Shielding Shielding
Table 9
