5. Technical specifications
MK 8
-
00
/MK 8
-
06
MK 16
-
00
/MK 16
-
06
Input tuner
8 × DVB
-
S/S2/S2x/T/T2/C
16 × DVB
-
S/S2/S2x/T/T2/C
Input frequency range
DVB
-
C | DVB
-
T/T2 | DVB
-
S/S2/S2X
50…898 MHz | 900…2150 MHz
Input level
DVB
-
C | DVB
-
T/T2 | DVB
-
S/S2/S2X
49…84 dBµV | 39…84 dBµV | 43...84 dBµV
LNB voltage
13/17 V; 22 kHz on/off; DiSEqC 1.0
LNB current per input (max.)
150 mA
Symbol rate
1,5…45 MS/s
Input error correction
automatic
Input connecto
r, female
8 × F
16 × F
Output TV channels
8 × DVB
-
C/DVB
-
T
16 × DVB
-
C/DVB
-
T
Output frequency range
DVB
-
C | DVB
-
T
111…1006 MHz | 111…862 MHz
Output channels DVB
-
C | DVB
-
T
S2…K87 | S2…K69
Output level adjustable
80…100 dBµV
Output modulation DVB
-
C | DVB
-
T
QAM 32, 64, 128, 256 | QPSK, QAM 16, 64
Output transmission symbol rate
1
-
7,5 M'Symbol sec
MER DVB-C | DVB-T
″
40 dB |
″
36 dB
FFT mode DVB
-
T
2k, 8k
FEC DVB
-
T
1/2, 2/3, 3/4, 5/6, 7/8
Output guard interval DVB
-
T
1/4, 1/8, 1/16, 1/32
Output connec
tor, female
1 × F
Test port output
-
30 dB
Data interface
2 × RJ45
Operation voltage
100…240 VAC/50…60 Hz
Power consumption
50 W
60 W
Ambient temperature range
(acc. to EN 60065)
-10°C…+50°C
Dimensions (W × H × D) appr.
480 × 253 × 47 mm
