Axis ME-01 User Manual

6 USER MANUAL ME-01
3. Technical data
Parameter
ME-01/A
ME-01/N
ME-01/N/25
Destination
to III class scales
one and two-ranged
with verification units number n  6000
Max verification units number
6000
Internal resolution
1:16 777 216
Power supply
AC: 230V 50Hz DC: 12V or
accumulator 6V ÷ 12 V
AC: 230V 50Hz
DC: 12V
Keyboard
Function buttons ( from 5 to 128 pcs.)
Or touch panel (touchpad)
Display
LED, LCD (alphanumeric or graphical)
Transducer supply voltage
DC: 5V or 5V keying (choper)
Voltage measurement range
-10 mV ÷ 10 mV or 0 mV ÷ 10 mV
Maximal voltage signal for stable loading
+ 10 mV
Minimal voltage signal for stable loading
- 10 mV or 0 mV
Minimal allowable input signal corresponding
to verification unit e
0,3 μV
Sensor impedance range
40÷4000 
Work temperature range
- 10 C ÷ +40 C
Part of limiting error
0,5
Sensor connecting
4 or 6 conductor system
Maximal cable length
75 m/mm
2
Primary measurement module functions
- gross and net mass indication
- automatic and semi-automatic zeroing
- semi-automatic tare,
- connection with computer (RS232C, RS485,
Ethernet, USB, radio)
- analogue output
- technological process steering
- and others
Enclosure type
OSA
OSN
ODN
Security level
IP40
IP65
Dimensions
190x140x70mm
200x146x77mm
238x182x77mm
Weight
1,8kg
2,3kg
2,3kg
The metrological parameters of the balance are indicated on the rating plate.
