USER MANUAL ME-01 7
4. Assembly
Assembly
ME-01/A
ME-01/N
ME-01/N/25
Meter grip
assembly
3 ways to mount
the meter to wall
Mounting to wall or
desktop
2 holes Ф5,
spacing 59mm
2 holes Ф5,
spacing 160mm
2 holes Ф5, spacing
203mm
