AXIS Q1602 Network Camera
Detectors
Note
Using the motion detection feature may decrease the prod uct’s overall perform a nce.
Set Up Motion Detection Windows
To set up a motion detection Include Window, f ollow these instructions:
1. Go to Detectors > Motion Detection.
2. Select the Configure Included W indows option and click New. Select the new window in the list of windows and enter
a descriptive nam e.
3. Adjustthesize(dragthebottomright-handcorner)andthepositio n (click on the text at the top and drag to the desired
position) of the window.
4. Adjust the Object Size, History and Sensitivity profile s lide rs (see
Motion Detection Parameters
for details). Any detected
motion within an active w indow is indicated by red peaks in the Activity window.
5. Click Save .
To exclude parts of the include w indow, select the Configure Excluded Windows and position the exclude window within the
include window.
To delete an include or exclude window, select the window in the list of w indows and click Del.
Motion Detection Parameters
The parameters controlling motion detection are described in the table below:
Parameter
Object Size
History
Sensitivity
Description
Object size rela tive to window
size.
Object memory length.
Difference in lum i nance
between background and
object.
High level (100%)
Only very large objects trigger
motion detection.
An object that appears in
the window triggers motion
detection for a long time
before it is considered as
non-moving.
Ordinary colored objects on
ordinary backgrounds trigger
motion
detection.
Medium level (50%)
A
large difference in luminan ce
is required to trigger m otion
detection.
27
