AXIS Q1602 Network Camera
Technical Specifications
Function/group
Installation a ids
in software
Focus assistant, remote back focus, pixel counter,
Installation,
management and
maintenance
Axis Camera Management tool on CD and web-based configuration
Configuration of backup and restore
Firmware upgrades over HTTP or FTP, firm ware available at www.axis.com
Casing
Metal (zinc)
Processor,
memory
ARTPEC-4, 256 MB RAM, 128 MB Flash
Battery backed-up real-time clock
Power
8-20 V DC or Power over Ethernet (PoE) IEEE 802.3af
max. 6.5 W , PoE Class 3
Connectors
RJ-45 10BASE-T/100BASE-TX PoE
Terminal block for 1 alarm input and 1 output
3.5 mm jack for mic in (max 80mVpp) or line mono input (max 6.2mVpp)
3.5 mm jack for line mono output (max 2.8Vpp) to active speaker
Edge storage
SD/SDHC memory card slot (card not included)
Support for recording to network share (Network Attached Storage or file server)
Operating
conditions
0 °C to 50 °C (32 °F to 122 °F)
humidity 20 - 80% RH (non-condensing)
Approvals
EN 55022 Class B, E N 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN
55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS
CISPR 22, KC, EN 60950-1, IEC60950-1
Dimensions
(HxWxD)
46 x 78 x 205 mm (1.8" x 3.1" x 8.1")
Weight
0.6 kg (1.3 lb)
Included
accessories
Stand, connector kit, Installatio n Guide, CD with installation tools, recording softw are
and User’s Manual, Windows decoder 1-user license
General
Video
management
software (not
included)
AXIS Camera Station - Video managem e nt software for viewing and recording up to 50
cameras
See www.axis.com/products/video/software/ for more software applications via partners
Optional
accessories
• AXIS T90A Illuminators
• A XIS T8412 Installation Display
• AXIS Pow er over
Ethernet Midspan 1-port, AXIS T8122 DC midspan
• AXIS Camera Sta tion and video management software from Axis’ Application
Development Partners
Performance Considerations
When settings up your system, it is impo rtant to co nsider how various settings and situations will affect performance . Some facto rs
affect the amount of bandwidth (the bit rate) required, others can affect the frame rate, and some affect both. If the load on the
CPU reaches its max im um , this will also affect the fra m e rate.
The following factors are among the most important to consider:
• High image resolution and/or low er compression levels res ult in images containing more data. Bandwidth affecte d.
• Access by large numbers o f Mo tion JPEG and/or unicast H.264 clients. Bandwidth affected.
• Simultaneous viewing of different streams (resolution, compression) by different clients. Effect on fram e rate a nd bandwidth.
• Accessing Motion JPEG a nd H.264 video streams sim ultane ous ly. Frame rate and ba ndwidth affected.
53
