AXIS Q1602 Network Camera
System Options
IEEE 802.1X
IEEE 802.1X is a s tandard for port-based Network Admission Control providing secure authentication of wired and wireless network
devices. IEEE 802.1X is based on EAP (Extensible Authentication Protocol).
To access a network protected by IEEE 802.1X, devices must authenticate themselves. The authentication is performed by a
third-party entity called an authe ntic ation server, typically a RADIUS server, examples of which are FreeRADIUS and Microsoft
Internet Authentication Service.
In Ax is ' implem entation, the netw ork device and the authentication server authenticate themse lves w ith the help of digital
certificates using EAP-TLS (Extensible Authentication Protocol - Tra nsport Layer Security). The certificates are provided by an
Certification Authority (CA). You need:
•aCAcertificate to validate the identity of the authentication server
• a CA-signed client certifica te and a private key to authenticate the network device.
To allow the network device to access a network protected by IEEE 802.1X:
1. Obtain a CA certificate, a client certificate and a client private key (contact your network administrator).
2. Go to Setup > System Options > Security > IEEE 802.1X and upload the CA certificate, the client certificate and the
client private key.
3. Under Settings, select the EAPOL version, provide your EAP id entity and private key password.
4. Check the box to enable IEEE 802.1X and click Save.
Certificates
CA Certificate The CA certificate is used to validate the identity of the authentication server. Enter the path to
the certificate directly, or locate the file using the Browse button. Then click U
pload.Toremove
acertificate, click Remove.
Client certificate
Client private key
The clie nt certificate and priva te key a re used to authen tica te the netw ork device. They can be
uploaded as se parate files or in one co m b ine d file (e.g. a PFX file or a PEM file). Use the Client
private key field if uploading one combined file. For each file, enter the path to the
file, or locate the
file using the Browse button. Then click Upload.Toremoveafile, click Remove.
Settings
EAPOL version
SelecttheEAPOLversion(1or2)asusedinyournetworkswitch.
EAP identity
Enter the user identity (maximum 16 characters) associated with your certificate.
Private key password
Enter the passwo rd (maximum
16 characters) for the private key.
Enable IEEE 80 2. 1X
Check the box to enable the IEEE 802.1X protocol.
Audio Support
Select Enable audio support to allow clients to re trie ve audio streams fro m the Axis product. For info rm ati on on how to configure
audio settings, see
Audio Settings, on page 20 .
Note
Deselecting this option will disable audio globally in the Axis product, for co n fi gured events a nd profiles with a udio as w ell .
Date & Time
The Axis product’s date and time settings are configured under System Options > Date & Time.
Current Server Time displays the current date and time (24h clock). The time can be displayed in 12h clock in the text overlay (see
below).
36
