AXIS Q1602 Network Camera
Technical Specifications
Technical Specifications
Function/group
Item
Specifications
Model
AXIS Q1602: Extended D1 resolution (768x576), indoor
Image sensor
Progressive scan RGB CMOS 1/3”
Lens
Varifocal 2.8 - 8 mm, F1.2, DC-iris, IR corrected, CS-mount
Horizontal angle of view 100°-34°
Vertical angle of view 75°-26°
Diagonal angle of view 135°-43°
Day and Night Automatically removable infrared-cut filter
Minimum
illumination
Color: 0.05 lux, F1.2
B/W: 0.008 lux, F1.2
Camera
Shutter time
1/29500 s to 2 s
Video
compression
H.264 (MPEG-4 Part 10/AVC)
H.264 Baseline and Main Profile
Motion JPEG
Resolutions
768 x 576 to 160 x 90
Frame rate H.264 30 fps in all resolutions
Frame rate
Motion JPEG
30 fps in all resolutions
Video streaming
Multi-stream H.264 and Motion JPEG
H.264: 3 individually configured streams in D1 and full fra m e rate
Motion JPEG: 3 individually configured stre ams in D1 and full frame rate
1 H.264 and 1 MJPEG streams in D1 and full frame rate
More str ea m s if identical or limited in frame rate or resolution
Controllable frame rate and bandwidth
VBR/CBR H.264
Image settings
Compression, color, brightness, sharpness, contrast, white balance, exposure control,
exposure zones, backlight compensation, fine tuning of behavio r at low light, wide
dynamic range - dynamic
contrast
Text and image overlay
Privacy mask
Mirroring of i
mages
Rotation: 0°, 90°, 180°, 270°
Corridor Format™
Users 20 simultaneous users
Unlimited numbers of users using mulicast (H.264)
51
