Parts Index
04
Model Number: MJ2325D/MJ2330D
951537 10" and 951540 12" Saw Bench (Box 1 of 2)
1 off: Saw Table on upper chassis (with motor, table insert, saw blade & NVR Switch fitted)
2 off: Side Panels & Front & Back Panels
4 off: Lower Leg Columns
1 off: Kickplate with four pre-drilled holes
1 off: Dust Extraction Moulding 100mm
1 off: Dust Extraction Hose 100mm
Bag Containing:
4 off:M6 x 15mm Phillips s crews, washers/nuts
4 off: M8 x 20mm Bolts, washers and nuts
20 off: M8 x 16mm Bolts, washers and nuts
1 off Extention Table
2 off: Extention Table Support Brackets
2 off: Clamping Plates with pre-drilled holes
Bag Containing:
8 off: M8 x 20mm Caphead Bolts and washers
2 off Hand Wheels with M5 x 12mm grub screws and locating keys
1 off: Mitre Fence and Mitre Fence Extension with clamping screw knobs
1 off: Mitre Fence Steel Plate with pre-driled holes
1 off: Saw Guard with Phillips screw/nut and coach bolt/knob
1 off: Riving knife
1 off: M6 x 40mm Coach bolt and knob
2 off: 125mm and 50mm Jubilee Clips
1 off: 30mm hose
Bag Containing:
1 off: Tommy Bar
1 off: Spanner for (Changing the Blade)
1 off: Push stick
Bag Containing:
2 off: 13/17mm Spanners
Allen Keys: 3,4,5,6 and 18mm
1 off: Instruction Manual
