Revision History of CP-SP-1147E
Date Rev. Revised pages Description
July 2003 1
Dec. 2003 2
Overall revision.
Dec. 2004 3
1-6,4-2
4-7
11-1
11-4
Panel mount type
The tightening torque of the terminal screw 0.4N·m or less→0.4 to 0.6N·m
changed.
1.Yamatake’s PGM10N/PGM10F series added.
A standard of temperature sensor about input type added.
•RTD input
Allowable wiring reistance, Effect of wiring resistance added.
•DC voltage input
Input impedance added.
z
Non-detected power failure time added.
May 2006 4
Cover, v
3-2
3-3
3-4
4-5
4-11
5-3
5-18
5-28
5-30
5-31 to 5-40
7-1
7-6
7-8
7-10
9-1
11-1
11-2
11-4
Manual name changed.
Handling precautions item added.
Plate thickness: more than 2mm→9mm or less changed.
Handling precautions item added.
Handling precautions item added.
Wiring diagram of

Connection of open collector output to digital input
changed.
Section 4-2 Recommended Cables added.
PV range tables totally changed.
Set value of operation type 33 added.
Explanation added.

MV scalling range added.
Old 5-30 to 5-39 pages.
Display Ct2 deleted.
C43 contents 10, 11 added. C46, C51 added. Handling Precautions added.
Display E1.C1 Contents 33 added. Handling Precautions added.
Old 7-9 page.

Alarm displays and corrective action
AL11 added. Handling Precautions added.
Indication accuracy explanation added. Diameter of the applicable
thermocouple or compensating wire added. Allowable input current added.
z
Current transformer input changed.
Dust-proof and drip-proof performance to degrees of protection changed.
Oct. 2007 5
i
v
1-3
5-3
11-1
11-4
APPLICABLE STANDARDS:
EN61326-1→EN61326 changed.
Description on SDC15 Quick Reference Guide added.
L-shaped plug adaptor added.
z
PV input range table (Thermocouple):
7 of C01 set value deleted.
Allowable input voltage added on DC current input.
Applicable standards:
EN61326-1→EN61326 changed.
Apr. 2012 6
Company name changed.
