7-5
Chapter 7. LIST OF SIMPLE CONFIGURATION DISPLAY ITEMS
7 - 3 List of Setup Setting Displays
Display Item Contents
Initial value
Notes
PV input range type When the PV input type is
thermocouple: 1 to 6, 9 to 11, 13
to 21, 23 to 25
1 For details, refer to the PV input
range table (on page 5-3).
When the PV input type is RTD:
41 to 46, 51 to 54, 63, 64, 67, 68
41
When the PV input type is DC
current/voltage: 84, 86 to 90
88
Temperature unit 0: Centigrade (˚C)
1: Fahrenheit (˚F)
0 Displayed when the PV input type
is thermocouple or RTD.
Decimal point
position
0: No decimal point
1 to 3: Digits after decimal point
0 Displayed when the PV input type
(selected by the model number)
is DC current/voltage, or when a
thermocouple or RTD range with a
decimal point is selected.
PV range low limit
When the PV input type is
thermocouple or RTD, the setting
is disabled and the input range
low limit selected with the PV
input type (
C01
) is displayed.
—
When the PV input type is DC
current/voltage, a value ranging
from -1999 to +9999 is set.
0
PV range high limit
When the PV input type is
thermocouple or RTD, the setting
is disabled and the input range
high limit selected with the PV
input type (C01) is displayed.
—
When the PV input type is DC
current/ voltage, a value ranging
from -1999 to +9999 is set.
1000
Control action
(Direct/Reverse)
0: Reverse action (Heat control)
1: Direct action (Cool control)
0
Displayed when the heat/cool
control is not used (C26=0).
Heat/Cool control 0: Disabled.
1: Enabled.
0
Displayed when two control output
points or event output is provided.
Heat/Cool control
dead zone
-100.0 to +100.0% 0.0 Displayed when using the heat/
cool control (
C26
=1).
LSP system group 1 to 4 1
CT1 operation type 0: Heater burnout detection
1: Current value measurement
0 Displayed when the optional
model has two current transformer
input points.
CT1 output 0: Control output 1
1: Control output 2
2: Event output 1
3: Event output 2
4: Event output 3
0 Displayed when the optional
model has two current
transformer input points and the
CT1 operation type is set at “heater
burnout detection” (C36 = 0).
CT1 measurement
wait time
30 to 300 ms. 30
CT2 operation type 0: Heater burnout detection
1: Current value measurement
0 Displayed when the optional
model has two current transformer
input points.
CT2 output 0: Control output 1
1: Control output 2
2: Event output 1
3: Event output 2
4: Event output 3
0 Displayed when the optional
model has two current transformer
input points and the CT2 operation
type is set at “heater burnout
detection” (C39 = 0).
CT2 measurement
wait time
30 to 300 ms. 30
To Next Page
