7-6
Chapter 7. LIST OF SIMPLE CONFIGURATION DISPLAY ITEMS
Display Item Contents Initial value Notes
Output 1 range 1: 4 to 20 mA
2: 0 to 20 mA
1 Displayed when the control output
1 of the model is the current output.
Output 1 type 0: MV
1: Heat MV (for heat/cool control)
2: Cool MV (for heat/cool control)
3: PV
4: PV value before bias
5: SP
6: Deviation
7: CT1 current value
8: CT2 current value
9: MFB (invalid on SDC15)
10: SP+MV
11: PV+MV
0
Displayed when the control output
1 of the model is the current
output.
The decimal point position of
the output 1 low limit/high limit
becomes 1 digit after the decimal
point when the output 1 type is
related to the MV and CT. When
the output 1 type is related to the
PV, SP, and deviation, the decimal
point position becomes the same
as that of the PV.
Control output 1
scaling low limit
-1999 to +9999
(The decimal point position may
vary depending on the output
1 type.)
0.0
Control output 1
scaling high limit
-1999 to +9999
(The decimal point position may
vary depending on the output
1 type.)
100.0
Control output 1 MV
scalable bandwidth
0 to 9999
The decimal point position and
unit are same as for PV.
200
If the controller model uses current
output for control output 1 and if
the control output 1 type is SP+MV
or PV+MV, this setting is displayed.
Control output 2
range
1: 4 to 20 mA
2: 0 to 20 mA
1 Displayed when the control output
2 of the model is the current output.
Control output 2 type 0: MV
1: Heat MV (for heat/cool control)
2: Cool MV (for heat/cool control)
3: PV
4: PV value before bias
5: SP
6: Deviation
7: CT1 current value
8: CT2 current value
9: MFB (invalid on SDC15)
10: SP+MV
11: PV+MV
3
Displayed when the control output
2 of the model is the current
output.
The decimal point position of
the output 2 input range low
limit/high limit becomes 1 digit
after the decimal point when the
output 2 type is related to the
MV and CT. When the output 2
type is related to the PV, SP, and
deviation, the decimal point
position becomes the same as that
of the PV.
Control output 2
scaling low limit
-1999 to +9999
(The decimal point position may
vary depending on the output
2 type.)
0
Control output 2
scaling high limit
-1999 to +9999
(The decimal point position may
vary depending on the output
2 type.)
1000
Control output 2 MV
scalable bandwidth
0 to 9999
The decimal point position and
unit are same as for PV.
200
If the controller model uses current
output for control output 2 and if
the control output 2 type is SP+MV
or PV+MV, this setting is displayed.
Handling Precautions
• If ROM version 1 of the instrument information bank(
I

d02
) is prior to 2.04,
SP+MV and PV+MV cannot be set in [Control output 1 type], [Control output 2
type], and [Auxiliary output type ].
• If ROM version 1 of the instrument information bank(
I

d02
) is prior to 2.04,
SP+MV and PV+MV cannot be set in [Control output 1 MV scaling],
[Control output 2 MV scaling], and [Auxiliary output MV scaling ].
