7-4
Chapter 7. LIST OF SIMPLE CONFIGURATION DISPLAY ITEMS
Display Item Contents Initial value Notes
Time proportional
cycle 1
5 to 120 s (when the output
includes the relay output)
1 to 120 s (when the output
does not include the relay
output)
10
or
2
When the output destination of the
time proportional output 1 includes
the relay output, the relay output
is operated with time proportional
cycle time of 5 s even though a
value less than 5 s is set.
Time proportional
cycle 2
5 to 120 s (when the output
includes the relay output)
1 to 120 s (when the output
does not include the relay
output)
10
or
2
Displayed when the heat/cool
control is used.
When the output destination of
the time proportional output 2
includes the relay output, the
relay output is operated with time
proportional cycle time of 5 s even
though a value less than 5 s is set.
AT type 0: Normal (Standard control
characteristics)
1: Immediate response (Control
characteristics immediately
responding to the external
disturbance.)
2: Stable (Control characteristics
with less up/down fluctuation
of PV)
1 Displayed when the control
method is other than ON/OFF
control (CtrL ≠ 0).
