Azbil C15 User Manual

3-2
Chapter 3. INSTALLATION

External dimensions
z
Model C15T (Panel Mount type)
Unit: mm
59
602
44.8
48
48
rdy
man
ev1 ev2 ev3 ot1 ot2
para
mode
SDC15
pv
sp
Mounting bracket
(Accessory)
Terminal
screw M3
z
Model C15S (Socket Mount type)
Terminal
screw
M3.5
2- M4
Mounting
hole
48
48
40
51
71
3.4
74.2
61.2
26.5
31
rdy
man
ev1 ev2 ev3 ot1 ot2
para
mode
SDC15
pv
sp
1
2
3
4
5
6
7
8
9
10
11
Socket
Stopper
Socket 81446391-001
(sold separately)

Panel cutout dimensions
For panel mounting type, make the mounting holes according to the panel hole
making dimensions.
Unit: mm
0
+0.5
45
50 min.
0
+0.5
4530 min.
0
+0.5
(48xN -3)
0
+0.5
45
("N" shows the number of mounting units.)
Stand-alone mounting Gang-mounting
Handling Precautions
• When three or more units are gang-mounted horizontally, the maximum
allowable ambient temperature is 40 °C.
• Provide a space of at least 50 mm or more above and below the controller.
• If dustproof or waterproof protection is required, mount the device
using the individual mounting method. If gangmounted, dustproof and
waterproof protection may not be maintained.
