Numeric value and character display on LED
Numeric values The 7-segment LED expresses numeric values as follows:
0 1 2 3 4
5 6 7 8 9
Alphabetical characters The 7-segment LED expresses alphabetical characters shown below. There are
some alphabetical characters, which are not displayed on the LED.
A B C D E
a b c d e
F G H I J
f g h i j
K L M N O
k l m n o
P Q R S T
p q r s t
U V Y Z –
u v y z
Handling Precautions
As shown above, numeric value “2” and alphabetic character “Z” are shown
in the same manner.
Accordingly, numeric value “5” and alphabetic character “S”, as well as
numeric value “9” and alphabetic character “Q” are also shown in the same
manner.
