4-6
Chapter 4. BASIC OPERATION
Note (Advanced use, direct setup function)
•
Control can be executed using an SP No. or SP value currently being
changed (indicated by blinking display) when the direct setup function
is enabled for the instantaneous flow rate direct setup function ON/OFF
(
C-2
1
in the function setup). In this case, the ENT key need not be pressed
to enter the SP value.
Handling Precautions
•
When switching the display by pressing the DISP key, first press the ENT
key to enter the SP value.
For details on how to set up functions, Chapter 5. ADVANCED
OPERATION.
Handling Precautions (Common to single setup and multi-setup)
•
When "1: Analog setup" is selected as the flow rate setup method (
C-03
in the function setup) and the SP value is controlled by external voltage
input, the SP value and SP No. cannot be changed with the or key.
•
If no operation is made for approximately 10 s after the operation stated
in (1) has been performed, the display automatically returns to the
instantaneous flow rate display.
•
If the DISP key is pressed during the operations in steps (2) and (3)
(setting is blinking), the SP No. and SP value return to their previous
values without saving of new values.
•
When the SP value is updated in step (3) for single setup or in step (4) for
multi-setup, the display automatically returns to the instantaneous flow
rate display after approximately 2 s have elapsed.
To Next Page
