5-17
Chapter 5. ADVANCED OPERATION
The flow rate range can be reduced to a level of 99 % down to 10 % of the standard range using the flow rate range
setup (C-24 or C-25). However, the minimum control flow rate is the same as for the standard range. As the range
is reduced, the setup and display resolution levels are improved as described in the table below.
Settings and display resolutions after change of range
MQV9005 MQV9020 MQV9200 MQV9500 *
Full scale flow rate
[mL/min]
Resolution
[mL/min]
Full scale flow rate
[mL/min]
Resolution
[mL/min]
Full scale flow rate
[mL/min]
Resolution
[mL/min]
Full scale flow rate
[L/min]
Resolution
[L/min]
5.00 to 3.02 0.02 — — — — 0.500 to 0.302 0.002
3.00 to 1.21 0.01 20.0 to 12.1 0.1 200 to 121 1 0.300 to 0.121 0.001
1.200 to 0.302 0.005 12.00 to 6.05 0.05 120.0 to 60.5 0.5 (120.0 to 60.5) (0.5)
0.600 to 0.302 0.002 6.00 to 3.02 0.02 60.0 to 30.2 0.2 (60.0 to 30.2) (0.2)
0.300 to 0.100 0.001 3.00 to 1.00 0.01 30.0 to 10.0 0.1 (30.0 to 10.0) (0.1)
*
The display unit of the flow rate shown in ( ) for the MQV9500 is mL/min.
MQV0002 MQV0005 MQV0020 MQV0050
Full scale flow rate
[L/min]
Resolution
[L/min]
Full scale flow rate
[L/min]
Resolution
[L/min]
Full scale flow rate
[L/min]
Resolution
[L/min]
Full scale flow rate
[L/min]
Resolution
[L/min]
— — 5.00 to 3.02 0.02 — — 50.0 to 30.2 0.2
2.00 to 1.21 0.01 3.00 to 1.21 0.01 20.0 to 12.1 0.1 30.0 to 12.1 0.1
1.200 to 0.605 0.005 1.200 to 0.605 0.005 12.00 to 6.05 0.05 12.0 to 6.05 0.05
0.600 to 0.302 0.002 0.600 to 0.302 0.002 6.00 to 3.02 0.02 6.00 to 3.02 0.02
0.300 to 0.100 0.001 0.300 to 0.100 0.001 3.00 to 1.00 0.01 3.00 to 1.00 0.01
MQV0200 MQV0500
Full scale flow rate
[L/min]
Resolution
[L/min]
Full scale flow rate
[L/min]
Resolution
[L/min]
— — 500 to 302 2
200 to 121 1 300 to 121 1
120.0 to 60.5 0.5 120.0 to 60.5 0.5
60.0 to 30.2 0.2 60.0 to 30.2 0.2
30.0 to 10.0 0.1 30.0 to 10.0 0.1
Handling Precautions
•
Even after flow rate range is changed, the accuracy specifications are the
same as for the standard range. (The full scale designated by % FS shows the
numeric value of the standard range.)
•
Even though the flow rate range is changed, the minimum control flow rate is
the same as for the standard range.
•
The scaling of the analog input/output is automatically changed to ensure
that the modified flow rate range is FS.
5 - 4 Flow Rate Range Change Function and Settings and
Display Resolutions After Change of Range
