Chapter 5. ADVANCED OPERATION

Parameter setup item list
No. Display Description
Factory
Setting
Setting Range
Related
Function Setup
Remarks
1
0.rnG
Flow rate OK judgment
range
(2 % FS) (0.5 to 100 % FS)
C-0 7
C-08
C-22
Unit : L/min (standard)
(mL/min (standard) for
the MQV9005/9020/9200.)
*1 *14 *14
2
0.hy5
Flow rate OK judgment
hysteresis
(1 % FS) (0.5 to 100 % FS)
*1 *14 *14
3
a.h1
Instantaneous flow rate
deviation upper limit
alarm
(10 % FS) (0.5 to 100 % FS)
C-15
C-16
*2
,
*3 *14 *14
4
a.h.hy
Instantaneous flow rate
deviation upper limit
alarm hysteresis
(2 % FS) (0.5 to 100 % FS)
*2
,
*3 *14 *14
5
a. lO
Instantaneous flow rate
deviation lower limit
alarm
(10 % FS) (0.5 to 100 % FS)
*2
,
*3 *14 *14
6
a.l.hy
Instantaneous flow rate
deviation lower limit
alarm hysteresis
(2 % FS) (0.5 to 100 % FS)
*2
,
*3 *14 *14
7
a.dly
Flow rate deviation
alarm/valve amperage
alarm judgment delay
time
10.0 s 0.5 to 999.9 s
C-15
C-16
C-20
*4
8
e.1.dl
Event 1 output delay 0.0 s 0.0 to 999.9 s
C-07
C-08
Delay does not apply to
totalizer pulse output.
*5
9
e.2.dl
Event 2 output delay 0.0 s 0.0 to 999.9 s
*5
10
c.f.
User setup conversion
factor
1.000 0.100 to 9.999
C-18
C-26
*6
11
a.i.h1
Valve amperage upper
limit alarm
100.0 % 0.1 to 100.0 %
C-16
C-20
At the factory setting, alarms
are not detected.
Handling Precautions,
P.5-14.
*7
12
a.i.lO
Valve amperage lower
limit alarm
0.0 % 0.0 to 99.9 %
*7
13
e.i.Sp
Event 1 output upper/
lower limit flow rate
setup
(0 % FS) (0 to 100 % FS)
C-07
C-08
Unit : L/min (standard)
(mL/min (standard) for
the MQV9200)
*8 *14 *14
14
e.2.Sp
Event 2 output upper/
lower limit flow rate
setup
(0 % FS) (0 to 100 % FS)
*14 *14
*8
