Unit Elements
4
Perfusor® compact, 2.1 gb 4 - 9
4.8 LS-Clip
Designation Ord. No.
LS-clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3450 7710
Exchange
1. Open unit (see „Open unit“ ➨ p. 4 - 3).
2. Press buzzer out of the holder.
3. Pull LS-clip out of the guide and exchange.
4. Assembly is done in reverse order.
Setting the Loudness of the Alarm Tone (from serial number
38100 on)
1. Open battery compartment (see „Battery Compartment Co-
ver“ ➨ p. 4 - 7).
2. Remove batteries.
3. Connect unit to mains and switch unit on.
4. Disconnect from mains for a short moment when the switch-
on test is finished. Pull mains connector and plug in again to
trigger a device alarm (code 22, continuous tone).
5. Put a small flat blade screw driver (carefully) through the
battery compartment opening and set the volume desired.
6. Switch unit off via the keyboard.
7. Insert batteries.
8. Close battery compartment.
Fig.: 4 - 9
LS-clip
Fig.: 4 - 10
