Perfusor® compact, 2.1 gb 4 - 15
11. Calibrate in Service Program (see „Calibration after Replace-
ment of Drive“ ➨ p. 7 - 1).
4.16 Drive Head
Designation Ord. No.
Drive head, complete . . . . . . . . . . . . . . . . . . . . . . . . . . 3450 1720
Toggle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3450 1711
Exchange
1. Open toggle, pull out drive head and close toggle again.
2. Pierce tamper-proof caps in drive head with a pointed screw
driver and remove caps.
Fig.: 4 - 18
Fig.: 4 - 19
Drive head with lock
and push-button sensor
