TERMINATION MODULE CONFIGURATION (NIDS01)
INTRODUCTION
C - 2 I-E96-207A
®
Table C-1. NIDS01 Application Summary
Interfaces To Connecting Cable
Application
Signal Type
Control Station
NDCS03 or IISAC01
NKTD01 24 VDC provides com-
munication between a
control module and a
control station.
Digital Indicator Station
NDIS01
NKTD01
Termination Module
NICS01
6634408 ribbon cable
Table C-2. NIDS01 Terminal Assignments
Terminal
Number
Assignment
1Common
2 +24 VDC
3 Manual/Auto 2 Select
4Lower 2
5 Raise/Lower 2 Common
6Raise 2
7 Manual/Auto 2 Power
8 Manual/Auto 2 Common
9 Manual/Auto 1 Select
10 Lower 1
11 Raise/Lower 1 Common
12 Raise 1
13 Manual/Auto 1 Power
14 Manual/Auto 1 Common
