Baldor VS1MX User Manual

2-2 General Information and Ratings MN762
2.3 VS1MX Ratings, Model Numbers and Frame Sizes
Table 2-1 Drive Ratings
HP Model Number kW Model Number HP kW
Current (Amps)
Frame
Watts
Loss
Input Output
110-115V +/-10% 1-Phase Input, 230V 3-Phase Output
VS1MX10P5 --- 0.5 --- 10.1 2.3 A 45
VS1MX11 --- 1 --- 18.9 4.3 A 90
VS1MX11P5 --- 1.5 --- 25.5 5.8 B 130
200-240V +/-10% 1-Phase Input, 230V 3-Phase Output
VS1MX80P5 VS1MX8K0P4 0.5 0.37 6.7 2.3 A 22
VS1MX81 VS1MX8K0P8 1 0.75 10.5 4.3 A 45
VS1MX82 VS1MX8K1P5 2 1.5 16.2 7 A 90
VS1MX82 VS1MX8K1P5 2 1.5 16.2 7 B 90
VS1MX83 VS1MX8K2P2 3 2.2 23.8 10.5 B 130
200-240V +/-10% 3-Phase Input
VS1MX20P5 VS1MX2K0P4 0.5 0.37 3 2.3 A 22
VS1MX21 VS1MX2K0P8 1 0.75 5.7 4.3 A 45
VS1MX22 VS1MX2K1P5 2 1.5 8.4 7 A 90
VS1MX22 VS1MX2K1P5 2 1.5 8.4 7 B 90
VS1MX23 VS1MX2K2P2 3 2.2 13.1 10.5 B 130
VS1MX25 VS1MX2K4 5 4 17.3 18 C 240
380-480V +/-10% 3-Phase Input
VS1MX41 VS1MX3K0P8 1 0.75 3.1 2.2 A 50
VS1MX42 VS1MX3K1P5 2 1.5 4.8 4.1 A 90
VS1MX42 VS1MX3K1P5 2 1.5 4.8 4.1 B 90
VS1MX43 VS1MX3K2P2 3 2.2 7.2 5.8 B 130
VS1MX45 VS1MX3K4 5 4 10.8 9.5 B 240
VS1MX47 VS1MX3K5P5 7.5 5.5 13.3 14 C 280
VS1MX410 VS1MX3K7P5 10 7.5 18.5 18 C 380
