Baldor VS1MX User Manual

Options and Kits D-1MN762
Appendix D
Options and Kits
D.1 Remote Keypad Option
The VS1MX Remote Keypad can be panel mounted for remote control or display of the drive. The remote keypad comes
with a standard 3.0 meter cable.
Table D-1 Remote Keypad
Catalog Number Description
VS1ST-RKEY3 VS1ST and VS1MX Remote Keypad and 9ft (3m) cable
Note: Template may be distorted due to reproduction
Figure D-1
2.17 (55)
2.76 (70)
1. Cut a rectangular opening at the enclosure mounting locating using Figure D-1 as a template.
2. Remove the covering from adhesive backing on the rear of the keypad.
3. The Remote keypad snaps into place. Simply press into the mounting location to seal.
4. Attach one end of the remote cable in the keypad connector of the control.
5. Attach the other end of the remote cable to the remote keypad.
D.2 Accessories
Optional Cables for VS1MX
Option cable assemblies for setting up and connecting a simple serial network.
Table D-2 Option Cables
Catalog Number Description
VS1ST-J45SP RJ45 Cable Splitter
VS1ST-CBL0P5 0.5m RJ45 Cable
VS1ST-CBL1 1m RJ45 Cable
VS1ST-CBL3 3m RJ45 Cable

Baldor VS1MX Specifications

General

Category	Controller
Enclosure Type	NEMA 1
Input Voltage	200-240V
Output Voltage	0-230 VAC
Control Method	V/F Control
Communication Port	RS485
Operating Temperature	-10°C to 40°C
Storage Temperature	-20 to 60°C
Humidity	5-95% RH, non-condensing
Dimensions	Varies by model
Weight	Varies by model
