Baldor VS1MX - E.7.2 Drive Error Codes

E-6 RS485/MODBUS Protocol MN762
Adr Description Data range Data format
145
Analog Input Format
(Analog In 1)
0-6
0: 0-10V
1: b 0-10V
2: 0-20mA
3: t 4-20mA
4: r 4-20mA
5: t 20-4mA
6: r 20-4mA
146 Voltage Boost 0-200 100 = 10.0%
147 Energy Savings 0, 1
0: Disable
1: Enable
148 Trip Log Last four trips (See E.7.2 Drive Error Codes)
149 PWM Frequency 0-5
0 = 4kHz,
1 = 8kHz,
2 = 12kHz
3 =16kHz,
4 = 24kHz,
5 = 32kHz
150 Relay Output 0-7 See user guide for function details
151 Display Speed Scale Factor 0-6000 100 = 0.100
152 Analog Output 0-9 See user guide for function details
153 Relay output limit 0-1000 100 = 10.0%
154 Skip Frequency 0 to P-06 Internal value (3000 = 50.0Hz)
155 Skip Frequency Band 0 to P-06 Internal value (3000 = 50.0Hz)
156 Restart Mode 0-3 See user guide for details
157 Auto Restart Attempts 0-6
0: Edgr-r
1: Auto_0
2-6: Auto_1 to Auto_5
158 Analog Input Offset -5000 to 5000 One decimal place 300=30.0%
159 Brake After Stop 0-600 seconds One decimal place 100=10.0 sec
160 Brake Before Start 0-1
0 - No brake.
1 - DC braking when run command is issued.
161 Decel2 Fast Stop 0-2500 Two decimal places 1000=10.00 sec
162 Brake Chopper Enable 0-2
0 : Disabled.
1 : Enabled.
2 : Enabled without s/w protection
Table E-6 Parameter Registers (Continued)
