General Information and Ratings 2-1MN762
Chapter 2
General Information and Ratings
The VS1MX is an adjustable frequency PWM drive operating in V/Hz (volts per hertz) mode. This chapter contains
information about the VS1MX drive, including how to identify the drive.
2.1 Identify the Drive by Model Number
Each drive can be identied by its model number, as shown in Figure 2-1. The model number is one the shipping label and
the drive nameplate. The model number includes the drive and any options.
Figure 2-1 Drive Identification
2.2 Storage Guidelines
Follow these recommendations to prolong drive life and performance if storing the drive:
1. Storage ambient temperature is -40°C to 60°C.
2. Storage Humidity range 10% to 95% RH non-condensing.
3. Do not expose to corrosive atmosphere.
VS1MX 4 10 - 4 TDF
VS1 Family
MX Microdrive
Voltage Code
Power Rating
Hp Rated kW Rated
0P5 = 0.5 0P4 = 0.37
1 = 1 0P8 = 0.75
2 = 2 1P5 = 1.5
3 = 3 2P2 = 2.2
5 = 5 4 = 4
7 = 7.5 5P5 = 5.5
Options
T = Internal Brake Transistor
D = Disconnect Switch
F = EMC Filter
2 = NEMA 12 / IP55
4 = NEMA 4X / IP66
(For Indoor Use Only)
Enclosure
Hp Rated kW Rated
1 = 115Vac 1PH -------
2 = 230Vac 3 PH 2k = 230Vac 3 PH
4 = 460Vac 3 PH 3k = 380-480Vac 3 PH
8 = 230Vac 1 PH 8k = 230Vac 1 PH
10 = 10 7P5 = 7.5
