8.2 Analog and Digital Input Configurations
Parameters P-07 and P-08 can be set to allow various operating modes. Following are settings for these parameters.
8.2.1 Terminal Strip Mode (P-07 = 0)
Table 8-1 Parameter P-08 Control of Digital Inputs when P-07=0
P-08 Digital In 1 (Term. 2) Digital In 2 (Term. 3) Digital In 3 (Term. 4) Analog Input 1 (Term. 6)
0
Open Stop Open FWD Run Open Analog Input 1
SPD Ref
Closed Run Closed REV Run Closed Preset Speed1
1
Open Stop Open Analog SPD Ref Open Preset Speed1
SPD Ref
Closed Run Closed
Preset Speed
1/2
Closed Preset Speed2
2*
Open Stop
Digital In 2 Digital In 3
Speed Select
Digital In 4*
Preset Speed 1-4
(Term 3) (Term 4) (Term 6)
0 0 Preset Speed 1 Open*
1 0 Preset Speed 2
Closed Run
0 1 Preset Speed 3
Closed * Max Speed (P-06)
1 1 Preset Speed 4
3*
Open Stop Open Analog SPD Ref Open Trip (Ext Trip)
SPD Ref
Closed Run Closed Preset Speed1 Closed Run
4
Open Stop Open Analog Input 1
Analog Input 2 SPD Ref
Closed Run Closed Analog Input 2
5*
Open FWD Stop Open REV Stop Open Analog SPD Ref
SPD Ref
Closed FWD Run Closed REV Run Closed Preset Speed1
6*
Open Stop Open FWD Run Open Trip (Ext Trip)
SPD Ref
Closed Run Closed REV Run Closed Run
7*
Open FWD Stop Open REV Stop Open Trip (Ext Trip)
SPD Ref
Closed FWD Run Closed REV Run Closed Run
8
Open Stop Open FWD Run
Digital In 3 Digital In 4* Speed Select
(Term 4) (Term 6)
Closed Run Closed REV Run 0 0 Preset Speed 1
9*
Open FWD Stop Open REV Stop 1 0 Preset Speed 2
Closed FWD Run Closed REV Run
0 1 Preset Speed 3
1 1 Preset Speed 4
10
3Wire Control
Momentary Close = RUN
3Wire Control
Open = STOP
Open Analog SPD Ref
SPD Ref
Closed Preset Speed 1
11*
3Wire Control
Momentary Close = RUN
3Wire Control
Open = STOP
3Wire Control
Momentary Closed = REV
SPD Ref
12
Open Stop Open Fast Stop (P33) Open Analog SPD Ref
SPD Ref
Closed RUN (ENABLE) Closed RUN (ENABLE) Closed Preset Speed1
*Table 8-1 notes:
P-08 = 2, 8 or 9 Note: Analog Input 1 becomes Digital Input 4
Closed: 8V< Analog Input1 < 30V
Open: Analog Input1 < 2V
P-08 = 5, 7 or 9 Note: Closing both Digital Input 1 and 2 = Fast Stop (P33).
P-08 = 3 or 6 Note: Connect external PTC Motor Thermistor or similar user contact to Digital Input 3.
P-08 = 11 Note: Closing both Digital Input 1 and Digital Input 3 = Fast Stop (P33).
