Table A-1 VS1MX Specifications
Input Ratings
Voltage 115 230 460
Voltage Range 99-126 198-264 342-528
Phase Single Phase
Single Phase and
Three Phase
Three Phase
Frequency 50/60Hz ±5%
Impedance 1% minimum from main connection
Output Ratings
Horsepower
1/2-1.5 HP 115VAC, 1 PH
1/2-3 HP 230VAC, 1PH
1/2-5 HP 230VAC, 3PH
1-10 HP 460VAC, 3PH
Overload
Capacity
150% for 1 minute; 175% for 2 seconds.
Frequency 0-500Hz
Voltage 0 to maximum input voltage (RMS)
Protective
Features
Trip
Missing control power, over current, over voltage, under voltage, over temperature (motor or
control), output shorted or grounded, motor overload
Stall Prevention Over voltage suppression, over current suppression
External Output LED trip condition indicators, 4 assignable logic outputs, 2 assignable analog outputs
Short Circuit Phase to phase, phase to ground
Electronic Motor
Overload
Meets UL508C (I2T)
Environmental
Conditions
Temperature -10 to 40°C De-rate 3% per degree C above 40°C to 45°C maximum ambient temperature
Cooling 0.5hp Natural; 1-10hp Forced air
Enclosure NEMA 12, NEMA 4X (Indoor Use Only)
Altitude
Sea level to 3300 Feet (1000 Meters)
De-rate 3% per 1000 Feet (303 Meters)
above 3300 Feet
Humidity 10 to 95% RH Non-Condensing
Shock 1G
Vibration 0.5G at 10Hz to 60Hz
Storage
Temperature
-40°C to +60°C
Duty Cycle 1.0
Control
Specications
Control Method V/Hz inverter
PWM Frequency Adjustable 4-32kHz
Speed Setting 0-10 VDC, 0-20mA; digital (keypad)
Accel/Decel 0-600 seconds
Analog Output 0-10VDC, 20mA (1k ohm)
Relay Output 30VDC@5A, 250VAC@6A
